Working platform »High«, pivoting
Greater flexibility, more applications, no blocking of roads or paths – the working platform with pivot function for space-saving application is particularly well suited to the municipal sector.
Features
» EC pre-certified
» Height gain: 1 m
» Anti-slip grid on floor
» Working height with front loader: max. 6500 mm
» Tool tray as standard
» Side entry
» See page 13 for accessories Technical details
» With Euronorm mounting as standard
» Optionally with individual welded farm, wheel or telescopic loader mounting
» Pivots up to 90° on both sides, total range of 180° (in 4 stages of 45°)
» Load capacity: approx. 250 kg
» Basket (L x W x H): 1570 x 920 x 1100 mm
