»Duplex« municipal blade

Name: »Duplex« municipal blade
SKU: PSSFLI300070
Price: 2740 EUR
Availability: InStock

Item #: PSSFLI300070

1600 mm / hydraulic / cat. municipal

Product illustrations are exemplary. Subject to change without notice.

»Duplex« municipal blade

Item #: PSSFLI300070

1600 mm / hydraulic / cat. municipal

Weight: 150 kg

Price

Incl. VAT: 3.260,60 €

Excl. VAT:

2.740,00 €

piece

This item is specially configured for you. For the exact delivery time, please contact us.

Forwarding agent - group 2

Description
Replacement items

Description

»Duplex« municipal blade
Technical details:

3 different blade positions possible: Angle, plough and V setting
Robust polyurethane scraper rails (130 mm x 20 mm) for low-noise snow clearing
Pivot angle: approx. 18°
Total width: 1700 mm
Incl. switching valve for operating all functions
1 double-acting connection required

Features:

Height-adjustable headstock
Spring-loaded overload protection
With edge lighting and support wheels
Painted version, RAL 2011 (deep orange)

Find similar articles

Attachment Line /

Distribution and levelling blades

Replacement items

Replacement parts

Support spindle

Ø60 - round 350mm

Art-Nr.: FNTXXX050224

Art-Nr.: FNTXXX901255

Swivel castor »heavy-duty«

Ø 200 mm / load capacity 450 kg / width 50 mm / solid rubber

Art-Nr.: SBWXXX030088

Torsion spring for levelling and snow remo...

thickness 8mm / length 182mm / Ø 26mm / galvanised

Art-Nr.: PSSFLI900116

1650 x 130 x 30 mm / 90° Shore

Art-Nr.: NKTXXX070139

Cylinder - hydr. pivoting headstock for Pr...

40/25/100 new version type Kastl / from year 2020

Art-Nr.: HZLXXX100197

Art-Nr.: ETZXXX915020

for Ø cable 8.0 mm / for socket 7-pin

Art-Nr.: ETZXXX915009

Aspöck Superpoint III LED marker light cur...

left

Art-Nr.: ETZXXX913058

Aspöck Superpoint III LED marker light cur...

right

Art-Nr.: ETZXXX913060

Intermediate cable for side marking

8 m / 2 x 1 mm² / with cigarette lighter

Art-Nr.: PSSFLI900117

Art-Nr.: HSLXXX020017

Art-Nr.: HSLXXX020006

Art-Nr.: HSLXXX020010

ext. Ø 50 mm / int. Ø 12.5 mm / thickness 6 mm

Art-Nr.: NKTXXX600200

Protection hose for hydraulic hose Ø 15mm

coloured RAL 9016 - orange

Art-Nr.: HSLXXX990120

Schlauchschutzspirale

für Ø 9mm

Art-Nr.: HSLXXX990014

Eyebolt loose for welding bolt - DIN 1434

D 16 / galvanized

Art-Nr.: NKTXXX253084

Split cotter pin DIN 94

4 x 32 mm / galvanised

Art-Nr.: NKTXXX195067

M 10 / 60 x 80 mm / galvanised

Art-Nr.: NKTXXX100240

Angle swivel-screw fitting

SWVE R3/8" - 8L

Art-Nr.: HVSXXX200037

Winkelverschraubung lang 45°

KOVO - 8L

Art-Nr.: HVSXXX500708

Umschaltventil elektrom.

DFE 5/6 - 12V

Art-Nr.: HSVWAL210004

Switch box 2-fold for snow removal blade l...

6000mm / 2x on/off latching / 7-pin plug

Art-Nr.: PSSFLI270205

Magnetic valve plug with overvoltage prote...

12V / 24 V - with LED / 2000mm

Art-Nr.: ETZXXX200005

for SVK plug construciton size 3

Art-Nr.: HZBXXX920030

for SVK plug construction size 3

Art-Nr.: HZBXXX920016

Art-Nr.: HZBXXX200032

Hexagon screw - DIN 931 / 8.8

M 30 x 140 - galvanized

Art-Nr.: NKTXXX190366

Hexagon screw DIN 931

M 16 x 60 / 8.8 / galvanised

Art-Nr.: NKTXXX190164

Hexagon screw DIN 931

M 16 x 50 / 8.8 / galvanised

Art-Nr.: NKTXXX190162

Hexagon screw DIN 931

M 24 x 280 / 8.8 / galvanised

Art-Nr.: NKTXXX190349

Hexagon screw - DIN 931 / 8.8

M 10 x 90 - galvanized

Art-Nr.: NKTXXX190054

Hexagon screw DIN 931

M 6 x 50 / 8.8 / galvanised

Art-Nr.: NKTXXX190402

Hexagon screw DIN 931

M 8 x 40 / 8.8 / galvanized

Art-Nr.: NKTXXX190418

Hexagon screw DIN 933

M 12 x 30 / 8.8 / galvanised

Art-Nr.: NKTXXX190076

Hexagon screw DIN 933

M 6 x 25 / 8.8 / galvanised

Art-Nr.: NKTXXX190630

Hexagon screw DIN 933

M 8 x 20 / 8.8 / galvanised

Art-Nr.: NKTXXX190004

Hexagon screw DIN 933

M 6 x 16 / 8.8 / galvanised

Art-Nr.: NKTXXX190626

Cylinder-head screw DIN 912

M 5 x 35 / 8.8 / galvanised

Art-Nr.: NKTXXX193409

Cylinder-head screw DIN 912

M 5 x 20 / 8.8 / galvanised

Art-Nr.: NKTXXX193400

Round-head screw DIN 603

M 10 x 25 / 8.8 / galvanised

Art-Nr.: NKTXXX161026

M 10 / 8 / galvanised

Art-Nr.: NKTXXX191008

M 24 / 8 / galvanised

Art-Nr.: NKTXXX191018

Art-Nr.: NKTXXX191004

M 12 / 8 / galvanised

Art-Nr.: NKTXXX191010

M 16 / 8 / galvanised

Art-Nr.: NKTXXX191014

M 30 / 8 / galvanised

Art-Nr.: NKTXXX191022

Ø 10.5 mm / without chamfer / galvanised

Art-Nr.: NKTXXX110108
